PICOMA 8249 6 ALUM ELBOW 90DEG 48RAD - Aluminum Rigid Conduit Elbow

The PICOMA 8249 is a 6-inch aluminum rigid conduit elbow designed to change the direction of a raceway by 90 degrees with a 48-inch radius. Suitable for electrical distributors and lighting solutions, it provides a durable connection point for wire and cable management in conduit systems. This elbow is a key component for switchgear suppliers requiring high-quality fittings for raceway installations.

Specifications

• Manufacturer: Picoma Industries
• Manufacturer Part #: 8249
• Application: Used to change the direction of a raceway
• Inside Diameter: 6.093 in.
• Outside Diameter: 6.625 in.
• Product Weight: 58 lbs
• Flexibility: No

Features

• Constructed from aluminum for corrosion resistance and lightweight durability
• 90-degree bend with 48-inch radius for smooth directional changes in conduit runs
• Threaded ends for secure attachment to raceway components
• Meets UL 6A and ANSI C80.5 standards for aluminum rigid conduit accessories (as referenced by Wheatland standards for similar products)

Downloads & Links

• Spec Sheet
