PICOMA 8017 6 ALUM ELBOW 90DEG 36RAD – Aluminum Rigid Conduit Elbow

The PICOMA 8017 6 ALUM ELBOW 90DEG 36RAD is an aluminum rigid conduit elbow designed to change the direction of a raceway by 90 degrees. It is suitable for use by electrical distributors and lighting solutions providers requiring durable conduit fittings. This elbow supports wire and cable installations by providing a reliable bend point within conduit systems. Manufactured by Picoma Industries, it is compatible with rigid aluminum conduit systems and serves as an essential component for switchgear suppliers and electrical contractors.

Specifications

• Manufacturer: Picoma Industries
• Manufacturer Part #: 8017
• Application: Used to change the direction of a raceway
• Inside Diameter: 6.093 in.
• Outside Diameter: 6.625 in.
• Product Weight: 42 lbs
• Flexibility: No

Features

• 90-degree bend with a 36-inch radius for smooth conduit transitions
• Constructed from aluminum for corrosion resistance and lightweight handling
• Threaded ends for secure and standardized conduit connections
• Designed to meet UL 6A and ANSI C80.5 standards for aluminum rigid conduit fittings (per Wheatland specifications)

Downloads & Links

• Spec Sheet
