PASS&SEYM. TM873-I RADIANT SWITCH 3W 15A 120/277V IV – Electrical Switch for Residential and Commercial Applications

The PASS&SEYM. TM873-I RADIANT Switch is a three-way electrical switch designed for residential and commercial lighting control applications. Manufactured by Pass & Seymour Wiring Devices & Accessories, this switch supports 15 Amp, 120/277 VAC circuits and features a thermoplastic construction for durability. It is suitable for wall mounting and provides reliable switching performance for lighting solutions, making it a practical component for electrical distributors and switchgear suppliers.

Specifications

• Application: Residential/Commercial
• Contact Rating: 15 Amp, 120/125 VAC
• Number of Poles: Single Pole, 3-Way
• Material: Thermoplastic
• Mounting: Wall
• Product Weight: 0.1400 lbs
• UPC: 785007245448
• Manufacturer Part #: TM873I

Features

• Part of the radiant¬Æ collection
• Smooth paddle action for ease of use
• High-impact resistant thermoplastic construction
• External screw-pressure-plate back and side wired, accepting #12 and #14 AWG wires
• Push-wire connection for #14 AWG solid copper wire
• Narrow back body design to provide more wiring space in the box
• Extra-long, through-body strap eliminates floating installations
• Easy-access green hex head ground screw
• Tri-drive ground, terminal, and mounting screws for secure installation
