PASS&SEYM. 2097TRUSBACGRY SELF-TEST GFCI REC TR 20A W/ USB AC GRY
SKU: #404493
Part: #2097TRUSBACGRY
UPC: 785007374667
PASS&SEYM. 2097TRUSBACGRY SELF-TEST GFCI REC TR 20A W/ USB AC GRY
SKU: #404493
Part: #2097TRUSBACGRY
UPC: 785007374667
Total Price: $69.28 per each Sold in increments of 1 each
Description
PASS&SEYM. 2097TRUSBACGRY Self-Test GFCI Receptacle with USB Charging
The PASS&SEYM. 2097TRUSBACGRY is a 20 Amp, 125VAC self-test Ground Fault Circuit Interrupter (GFCI) receptacle with integrated USB Type-A and Type-C charging ports. Designed for use by electrical distributors and lighting solutions providers, this device combines traditional power outlets with USB charging capability, making it suitable for residential and commercial applications requiring enhanced electrical safety and convenient device charging. The receptacle features SafeLock® Protection to ensure reliable ground fault protection and complies with National Electric Code® tamper-resistant requirements.
Specifications
- Manufacturer: Pass & Seymour Wiring Devices & Accessories
- Manufacturer Part #: 2097TRUSBACGRY
- Rating: 20 Amp, 125VAC, 60Hz
- Number of Poles: Double Pole
- Material: Polycarbonate
- Dimensions (W x H x L): 2 in x 4.8 in x 2.6 in
- Product Weight: 0.3 lbs
- USB Charging: Type-A and Type-C ports sharing 2.0A charging capacity
- UPC: 785007374667
Features
- Self-Test functionality with automatic testing every three seconds and indicator light to signal device failure
- SafeLock® Protection disconnects power if critical components are damaged
- Includes two USB ports (Type-A and Type-C) for convenient device charging alongside traditional power outlets
- Tamper-resistant automatic shutter system to prevent insertion of foreign objects
- Side or internal screw-pressure-plate back wire termination compatible with #14–#10 AWG copper or copper-clad conductors
- Captive screws and ground terminal clamp for easier and faster installation
- Two back-wire holes per termination for wiring flexibility and space saving
- Prevents line-load reversal miswire to ensure no power if wired incorrectly
- High-impact-resistant thermoplastic construction for durability
- Auto-ground clip assures positive grounding to metal boxes
- Exceeds UL943 voltage surge requirements
- Meets National Electric Code® Tamper-Resistant Requirements
- RoHS and Proposition 65 compliant
- Feed-thru wiring configuration allows protection of downstream receptacles
