PASS&SEYM. 2097-NTLTRW RADIANT SLFTST TR RECEP/NLITE GFI 20A WH - GFCI Receptacle

The PASS&SEYM. 2097-NTLTRW is a radiant® tamper-resistant self-test night light GFCI receptacle designed for commercial and residential electrical applications. This device provides ground fault protection with SafeLock® technology, ensuring safety by automatically testing every three seconds and disconnecting power if protection is lost. Ideal for electrical distributors and lighting solutions providers, it features a built-in LED night light with photocell sensor for automatic illumination in low light conditions. The receptacle supports back and side wiring, suitable for wire and cable installations, and is compliant with UL standards and RoHS regulations.

Specifications

• Application: Commercial/Residential
• Amperage Rating: 20A
• Frequency Rating: 60 Hz
• Interrupt Rating: 4 to 6 mA
• Number of Poles: 2
• Material: Polycarbonate
• Connection: Back and Side Wire
• Operating Temperature: -35¬∞C to +66¬∞C
• Environmental Conditions: 95% Humidity, UL 94 V2
• Dimensions (HxWxL): 4.2 in x 1.73 in x 1.03 in
• Product Weight: 0.25 lbs
• UPC: 785007047790
• Manufacturer: Pass & Seymour Wiring Devices & Accessories
• Manufacturer Part #: 2097NTLTRW

Features

• Self-Test GFCI with SafeLock¬Æ Protection automatically tests every three seconds
• Tamper-resistant shutter system meets National Electrical Code¬Æ requirements
• Sealed night light with high-impact-resistant Lexan¬Æ lens prevents tampering
• Energy-efficient LED night light with 20-year average life expectancy
• Photocell sensor turns night light ON in darkness and OFF in daylight
• Feed-through wiring allows protection of downstream receptacles
• Auto-Ground Clip ensures positive grounding to metal boxes
• Trip indicator light (red LED) signals device status
• Side or internal screw-pressure-plate back wire compatible with #10‚Äì#14 AWG solid or stranded wire
• RoHS and Proposition 65 compliant
• Mounting screws shipped captive for easier installation
