PANELS & TROFFERS 3484-5882 Lumens SWISH Field Adjustable 2x4 LED Panel

This SWISH field-adjustable LED panel by RAB is designed for indoor recessed ceiling applications, providing versatile lighting solutions suitable for electrical distributors and lighting professionals. It offers adjustable power and color temperature settings to meet diverse lighting needs in commercial and institutional environments. The fixture supports 0-10V dimming and operates on universal voltage from 120V to 277V, making it compatible with a wide range of electrical systems.

Specifications

• Manufacturer: RAB
• Model Number: SWISHFA2X4/D10
• Lumens: 3,484 lumens
• Efficacy: 119 lumens per watt
• Input Wattage: 26 watts
• Color Rendering Index (CRI): 83
• Lens Material: Frosted Polycarbonate
• Dimensions (L x W x H): 52.4" x 26.6" x 4.8"
• Product Weight: 25.5 lbs
• Operating Ambient Temperature: Up to 104°F
• Minimum Starting Temperature: -22°F
• Voltage: 120-277V, 50/60 Hz

Features

• Field-adjustable power settings: 29W, 39W, and 49W
• Field-adjustable color temperature: 3500K, 4000K, and 5000K
• 0-10V dimmable driver for smooth dimming control
• Suitable for recessed ceiling mounting with flat tee grid ceiling compatibility
• Type IC rated and inherently protected for safe installation in insulated ceilings
• Suitable for damp locations
• Easy installation with pre-installed grid clips and support wire holes
• Universal voltage driver supports operation across a wide voltage range
• Battery backup option available for emergency lighting compliance

Downloads & Links

• Instructions
