OSRAM LED24T5HOL48FGDIM830SUBG9 LED T5HO High Output Lamp

The OSRAM LED24T5HOL48FGDIM830SUBG9 is a high output LED T5 linear lamp designed as an energy-efficient replacement for traditional fluorescent T5HO lamps. It provides instant, uniform light distribution without mercury, suitable for use in dry and damp locations. This product is engineered for compatibility with select programmed rapid start electronic T5 ballasts, making it ideal for electrical distributors and lighting solutions providers seeking reliable, dimmable LED options for commercial and industrial lighting applications.

Specifications

• Wattage: 24 Watts
• Base Type: G5
• Replaces: FP54/830/HO/ECO fluorescent lamps
• Average Life: 50,000 hours (L70)
• Typical Lumens: 3400 lm
• Color Rendering Index (CRI): 82
• Color Temperature: 3000K
• Power Factor: >0.90
• Bulb Finish: Frosted Glass
• System Power: 56 Watts (with 2 lamps)
• System Lumens: 7000 lm (with 2 lamps)
• System Efficacy: 125 lm/W
• Operating Temperature Range: -4¬∞F to +113¬∞F (-20¬∞C to +45¬∞C)
• Max Case Temperature: 167¬∞F (75¬∞C)
• Length: 45.8 in (1163 mm) max overall
• UPC: 046135415920
• Product Weight: 9.78 lbs

Features

• Compatible with select programmed rapid start electronic T5 ballasts (120-277V and 347V)
• Dimmable down to 10% with 0-10V compatible dimmable ballasts
• No lamp polarity required
• Instant-on with full light output and stable lamp-to-lamp color
• Beam angle of 180¬∞ with frosted glass optics and 320¬∞ light emitting angle
• No UV emission and mercury-free
• Suitable for dry and damp locations
• Energy savings of approximately 53% compared to traditional fluorescent T5HO lamps
• Covered by a 5-year limited warranty under the NLB Trusted Warranty Program
• Certifications: cETLus, RoHS, FCC, NSF, Lead Free, Mercury Free, DLC 5.1
