Offset Solid Pin Terminal Connectors 750 MCM To 500 MCM – Electrical Connectors

These Offset Solid Pin Terminal Connectors are designed for reliable electrical connections, specifically for terminating 750 MCM AWG cable to 500 MCM pin sizes. Manufactured from high-strength 6061-T6 aluminum alloy with a tin-plated finish, they are suitable for aluminum to copper cable terminations, making them ideal for electrical distributors and switchgear suppliers handling wire and cable installations.

Specifications

• Material: 6061-T6 Aluminum
• Color Coding: Yellow
• Manufacturer Part #: 90994
• Voltage Rating: 600V
• Wire Range: #6 thru 750 MCM (Conductor Size), #4 thru 500 MCM (Pin Size)
• Product Weight: 0.5850 lbs
• Certifications: UL, cUL, RoHS Compliant

Features

• Electro tin-plated for corrosion resistance
• AL9CU rated for use with copper or aluminum conductors
• Oxide inhibitor coated barrel to prevent oxidation
• EDPM rubber insulating cover for enhanced insulation
• Offset solid copper pin design for secure connections
