Nylon Fully-Insulated Female Disconnect, 22-18 AWG – Electrical Wire Connector

This Nylon Fully-Insulated Female Disconnect, designed and manufactured by IDEAL Industries, serves as a reliable electrical wire connector suitable for various electrical systems. It is engineered for use with wire sizes ranging from 22 to 18 AWG and provides a secure female connection. This product is ideal for electrical distributors and switchgear suppliers requiring durable and color-coded insulated terminals for efficient wire and cable management.

Specifications

• Manufacturer: IDEAL Industries
• Manufacturer Part #: 83-9771
• Connection Type: Female
• Wire Range: 22-18 AWG (0.5 - 1.0 mm²)
• Insulation Diameter: 0.150 in (3.8 mm)
• Material: Brass, Nylon
• Finish: Tin-Plated
• Dimensions (inches): Length 0.866, Width 0.260, Height 0.433
• Product Weight: 0.1000 lbs
• UPC: 783250490660

Features

• Color-coded insulated terminals for easy wire size identification
• Durable nylon insulation for electrical safety and protection
• Tin-plated brass construction ensures corrosion resistance and reliable conductivity
• Packaged in a durable plastic box for convenient storage and handling
