Description
Non-insulated Tin Plated YA4C2LN Copper Compression Lug – Wire Termination
The Burndy YA4C2LN copper compression lug is designed for wire termination applications, providing reliable electrical connections in industrial and commercial settings. This terminal lug is suitable for use by electrical distributors and switchgear suppliers requiring durable wire and cable accessories. Its tin-plated copper construction ensures excellent conductivity and corrosion resistance, making it a dependable choice for lighting solutions and other electrical systems.
Specifications
- Material: Copper
- Conductor Size: 4 American Wire Gauge (AWG)
- Connection Type: Terminal
- Hole Size: 14 millimeters
- Stud Size: 1/2 inch
- Stud Hole Spacing: 1-3/4 inches
- Color Coding: Gray
- Maximum Voltage: 35,000 volts
- Temperature Rating: 90°C
- Wire Strip Length: 7/8 inch
- Number of Holes: 2
- Tongue Angle: Straight
- UL Listed: Yes
- CSA Approved: Yes
- Plating Type: Tin - Electro Plated
- Length Overall: 4.14 inches (105 mm)
- B Length: 13/16 inch (0.81 inch)
- Bolt Hole Size: 0.52 inch
- Outside Diameter: 0.34 inch
- Pad Width: 0.83 inch
- D Dimension: 3.02 inches
- N Dimension: 0.63 inch
- Z Dimension: 0.64 inch
- Product Weight: 0.0900 lbs
- UPC: 781810501474
Features
- Standard barrel with short barrel design for compact installations
- Chamfered and skived barrel style for ease of wire insertion and improved crimping
- Inspection window for visual verification of proper conductor insertion
- Tin plating enhances corrosion resistance and electrical conductivity
- Compatible with a wide range of mechanical, hydraulic, and dieless crimping tools
- Suitable for commercial stranded copper conductors
- Color-coded gray for easy identification
- UL Listed for 600 V to 35 kV applications
