Description
Features
- Compact Size Saves Space and Helps Reduce Overall Panel Size
- Interchangeable Lugs and Nut Keepers for Customer-Supplied Connections Allow for Last Minute Changes on Site
- Integral Din Rail or Base Mounting Capability Simplifies Mounting the Breaker without Having to Add Plates or Adapters
- Overcenter Toggle and Trip Free Mechanism
- Suitable for Reverse Feed Applications
- Common Trip
- RoHS Compliant
Additional Information
- Overall Dimension 2.96 Inch Width x 2.87 Inch Depth x 4.99 Inch Height
Specifications
- Type: Thermal Magnetic, Molded Case
- Voltage Rating: 600 Volt
- Current Rating: 20 Ampere at 40 Deg C
- Number of Poles: 3
- Interrupting Rating: 14 Kiloamp
- Application: Reverse Feed
- Used On: P1/P2/P3/P4/P5 Panelboard
- Approval: UL 489
- Series/Model: NGB
Downloads
CatalogMore Information
Manufacturer Catalog Number
NGB-3-B020
Weight
2.5500
Applications
Reverse Feed
Current
20 amperes
Number Of Poles
3
Voltage
600 volts
