N7899-HGI, 20 Amp
N7899-HGI, 20 Amp
Total Price: $31.97 per each Sold in increments of 1 each
Description
Specifications
AC Horsepower Ratings
- At Rated Voltage: 1 HP
Electrical Specifications
- Amperage: 20 Amp
- Voltage: 125 Volt
- Pole: 2
- Wire: 3
- Frequency (Hertz): 60
- Short Circuit Current Rating: 10kA
- Feed-Through Current: 20 Amp
Environmental Specifications
- Flammability: Rated V-0 per UL94
- Operating Temperature: -35C-+66C
Material Specifications
- Face Material: PBT
- Body Material: Polycarbonate
- Terminal Screws: Plated Steel
- Grounding Screw: Plated Steel
- Clamps: Brass
- Strap Material: Galvanized Steel
Mechanical Specifications
- Terminal Accom.: 14-10 AWG
- Product ID: Ratings permanently marked on device
Performance Data
- Trip Level: Class A, 5mA plus or minus 1mA
- Diagnostics: LED
Product Features
- Color: Ivory
- Country of Origin: China
Standards and Certifications
- NEMA: WD-1 & WD-6
- ANSI: C-73
- UL 498: File E13399
- CSA C22.2 No. 42: File LR-57811
- NOM: 057
- UL 943: File E48380
- UL Fed Spec WC-596: Yes
Warranty
- Warranty: 2-Year Limited
Downloads
Product BrochureInstruction Sheet
More Information
Manufacturer Catalog Number
N7899-HGI
Weight
0.378
Material
Galvanized Steel
Color
Ivory
Amperage
20 amperes
Flammability Class
Rated V-0 Per UL94
Frequency
60 hertz
Nema
WD-1
Number Of Poles
2
Number Of Wires
3
Operating Temperature
-35 To 66 degrees celsius
Voltage
125 volts
Warranty Length
2 years
