MPDB UL1953 AL LARGE 1000V 840A 3-pole 2 600-#2 in-8 #4-#14&3/0-#10 out Box/Box
SKU: #374950
Part: #MPDB69543
UPC: 782001454821
MPDB UL1953 AL LARGE 1000V 840A 3-pole 2 600-#2 in-8 #4-#14&3/0-#10 out Box/Box
SKU: #374950
Part: #MPDB69543
UPC: 782001454821
Description
MPDB UL1953 AL LARGE 1000V 840A 3-pole 2 600-#2 in-8 #4-#14&3/0-#10 out Box/Box Power Distribution Block
The MPDB UL1953 AL Large Power Distribution Block by Mersen is designed for efficient splicing of cables, splitting primary power into secondary circuits, and serving as fixed junction tap-off points. This product is suitable for electrical distributors and switchgear suppliers requiring reliable wire and cable management in industrial and commercial electrical installations. It supports high amperage loads and meets UL and CSA standards, ensuring compliance with UL508A and the National Electrical Code® for feeder and branch circuit applications.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: MPDB69543
- Amperage Rating: 840 A
- Amperage: 680 amperes
- Number of Poles: 3
- Material: Tin-plated Aluminum
- Connector Material: Tin-plated Aluminum
- Mounting: Direct Screw Mount
- Connection: Box To Box
- Max. Operating Temperature: 80 degrees Celsius
- Dimensions (L x W x H): 5.7 in x 7.89 in x 3.55 in
- Product Weight: 5.4 lbs
- Country of Origin: Mexico
- UPC: 782001454821
Features
- Safe and easy method for splicing cables and splitting primary power into secondary circuits
- Meets spacing requirements for feeder and branch circuits in conjunction with UL508A and National Electrical Code®
- UL Listed to subject 1953, File E352417 and CSA Certified Class 6228 01
- Available in aluminum with tin-plated connectors for corrosion resistance and conductivity
- Supports high amperage applications up to 840 A
- Designed for fixed junction tap-off points
