Medium Voltage Fuse 5500V 15A E-Rated Ferrule Mount Striker D0R0 Series - Transformer Protection Fuse

This Medium Voltage Fuse is designed for the protection of transformers and distribution systems operating up to 5.5 kV. It provides reliable overload and short circuit protection with current-limiting capabilities, melting at currents as low as 1.7 times its rated amperage up to its maximum interrupting rating. The fuse is engineered to withstand transformer magnetizing inrush currents and is suitable for use by electrical distributors and switchgear suppliers requiring robust protection solutions in medium voltage electrical networks.

Specifications

• Manufacturer: Mersen
• Manufacturer Part #: A055F1D0R0-15E
• Voltage Rating: 5.5 kV
• Amperage Rating: 15 A
• Interrupting Rating: 63 kA RMS Symmetrical
• Mounting Type: Clip
• Connection Type: Ferrule
• Dimensions: Length 15.88 in, Diameter 3 in, Width 3 in, Height 3 in
• Maximum Operating Temperature: 80 °C
• Product Weight: 10 lbs
• Country of Origin: Mexico
• UPC: 782001804152

Features

• UL listed for compatibility with UL listed equipment
• Current-limiting fuse for superior equipment protection
• Ferrule mounting compatible with standard clips and interchangeable with other fuse brands
• Non-venting design ensures silent operation
• Metal embossed catalog number and manufacturing date for durable identification
• Designed to withstand transformer magnetizing inrush current
• Suitable for use indoors or outdoors when mounted in weatherproof enclosures
• Blown-fuse indicator provides positive identification of open fuse
