Medium Voltage Fuse 38000V 5A E-Rated Ferrule Mount Striker FPK Series
SKU: #194103
Part: #9F60FPK005
UPC: 782001397272
Medium Voltage Fuse 38000V 5A E-Rated Ferrule Mount Striker FPK Series
SKU: #194103
Part: #9F60FPK005
UPC: 782001397272
Description
Medium Voltage Fuse 38000V 5A E-Rated Ferrule Mount Striker FPK Series
The Medium Voltage Fuse 38000V 5A E-Rated Ferrule Mount Striker FPK Series by Mersen is designed for the protection of transformers and distribution systems operating between 26 kV and 38 kV. This current-limiting fuse provides reliable overload and short circuit protection, melting at currents as low as 1.7 times its rated amperage up to its maximum interrupting rating. Engineered to withstand transformer magnetizing inrush currents, it is suitable for use by electrical distributors and switchgear suppliers requiring robust and precise protective components in medium voltage applications.
Specifications
- Manufacturer: Mersen
- Manufacturer Part #: 9F60FPK005
- Amperage Rating: 5 A
- Voltage Rating: 38,000 V (38 kV)
- Interrupting Rating: 26 kA RMS Symmetrical
- Mounting Type: Clip
- Connection: Ferrule
- Dimensions (L x W x H): 30.81 in x 3 in x 3 in
- Diameter: 3 inches
- Product Weight: 14 lbs
- Maximum Operating Temperature: 80°C
- Country of Origin: Mexico
- Application: Protection for 26 kV to 38 kV transformers or distribution systems
Features
- Current-limiting fuse designed to melt at currents as low as 1.7 times the rated amperage
- Withstands transformer magnetizing inrush current
- Ferrule mounting compatible with standard clips and interchangeable with other brands
- Spring reinforced clip mounting for secure installation
- E-Rated fuse for general purpose medium voltage protection
- Non-venting design for silent operation
- Metal embossed catalog number and manufacturing date for lasting identification
- Suitable for indoor or outdoor use in weatherproof enclosures
- Blown-fuse indicator for positive identification of open fuse
