Medium Voltage Fuse 38000V 1A E-Rated Ferrule Mount Striker FPK Series

The Medium Voltage Fuse 38000V 1A E-Rated Ferrule Mount Striker FPK Series by Mersen is designed for protection of transformers and distribution systems operating between 26 kV and 38 kV. This current-limiting fuse provides overload and short circuit protection, melting at currents as low as 1.7 times its rated amperage up to its maximum interrupting rating. Engineered to withstand transformer magnetizing inrush currents, it is suitable for use by electrical distributors and switchgear suppliers in medium voltage applications.

Specifications

• Application: Protection for 26 kV to 38 kV transformers or distribution systems
• Amperage Rating: 1 A
• Interrupt Rating: 26 kA
• Dimensions (L x W x H): 30.81 in x 3 in x 3 in
• Diameter: 3 inches
• Mounting Type: Clip
• Connection: Ferrule
• Max Operating Temperature: 80 degrees Celsius
• Product Weight: 14 lbs
• Manufacturer: Mersen
• Country of Origin: Mexico
• Manufacturer Part Number: 9F60FPK001

Features

• Current-limiting fuse for superior equipment protection
• Designed to withstand transformer magnetizing inrush current
• Ferrule mounting compatible with standard clips and interchangeable with other brands
• Non-venting design for silent operation
• Metal embossed catalog number and manufacturing date for durable identification
• Mounted in spring reinforced clips
• UL listed for compatibility with UL listed equipment
• Suitable for indoor or outdoor use in weatherproof enclosures
• Blown-fuse indicator for positive identification of open fuse
