Medium Voltage Fuse 15500V 0.5A E-Rated Ferrule Mount Striker DMH Series – Transformer Protection Fuse

This Medium Voltage Fuse from Mersen is designed for protection of 12 kV to 15.5 kV transformers or distribution systems. It provides reliable overload and short circuit protection through current-limiting technology that melts at currents as low as 1.7 times the fuse current rating, up to its maximum interrupting rating. The fuse is engineered to withstand transformer magnetizing inrush currents and is ferrule-mounted for compatibility with standard clips, making it suitable for use by electrical distributors and switchgear suppliers in medium voltage applications.

Specifications

• Voltage Rating: 15.5 kV
• Amperage Rating: 0.5 A
• Interrupting Rating: 50 kA (up to 120 kA per catalog)
• Dimensions: Length 17.2 in, Diameter 2 in, Width 2 in, Height 2 in
• Mounting Type: Clip
• Connection: Ferrule
• Maximum Operating Temperature: 80 °C
• Product Weight: 4.25 lb
• Country of Origin: Mexico
• Manufacturer Part Number: 9F60DMH905

Features

• UL listed for compatibility with UL listed equipment
• Ferrule mounting designed for standard clips and interchangeable with other fuse brands
• Current-limiting fuse provides superior equipment protection
• Non-venting design ensures silent operation
• Metal embossed catalog number and manufacturing date for durable identification
• Designed for outdoor usage in 9F60 type EJO applications
• Blown-fuse indicator for positive identification of open fuse
