MC Cable Connector, SS, 3/4" NPT, range over jacket 1.080 - 1.205, range over armor .970 - 1.125
SKU: #371668
Part: #RTKSS-075-6
UPC: 785411817675
MC Cable Connector, SS, 3/4" NPT, range over jacket 1.080 - 1.205, range over armor .970 - 1.125
SKU: #371668
Part: #RTKSS-075-6
UPC: 785411817675
Description
MC Cable Connector, Stainless Steel, 3/4" NPT – Electrical Connector
The Remke MC Cable Connector in stainless steel is designed for secure and reliable connections of metal-clad (MC) cables in electrical distribution and lighting solutions. It provides a watertight seal around jacketed armored cable and at enclosure entries, suitable for use in wet or dry locations. This connector is ideal for electrical distributors and switchgear suppliers requiring durable and easy-to-install cable connectors for industrial and commercial applications.
Specifications
- Material: Stainless Steel
- Color: Ivory
- Dimensions (L x W x H): 3.21 in x 2.2 in x 2.2 in
- Product Weight: 1.0790 lbs
- Hub Size: 3/4" NPT
- Cable Range Over Jacket: 1.080" - 1.205"
- Cable Range Over Armor: 0.970" - 1.125"
- Temperature Range: -40°C to 121°C
- Country of Origin: United States
- Made in USA: Yes
- Manufacturer Part #: RTKSS-075-6
- UPC: 785411817675
Features
- One-piece compact PowR-Lock™ design for easy installation without disassembly
- Neoprene bushing provides superior pull-out and sealing protection
- Embedded Buna-N O-ring for watertight seal (Viton® available)
- Rated NEMA 4 and IP65 for wet and dry locations
- Suitable for indoor and outdoor vertical or horizontal cable runs
- Meets UL standards for raintight metal clad cable fittings
