Features

• Superior color stability— within ±200K
• Lamp to lamp color consistency over life higher lumen maintenance
• Improved lumen maintenance over standard metal halide
• Feature ALTO lamp technology with reduced mercury
• Operate on existing ballasts
• Lamps feature integrated UV blocking medium for reduced fading of fabrics and paintings
• 35 and 70 watt flood and spot, 3000, and 4000K versions

Benefits

• Philips MC PAR30L lamps deliver improved lumen maintenance over standard metal halide PAR lamps.
• Philips MC PAR30L lamps reduce lighting cost of ownership - they are an energy efficient alternative to incandescent or halogen PAR lamps.

Applications

• Ideal for retail accent and display lighting and architectural lighting for interior and exterior applications.

Warning And Safety

• WARNING: These lamps can cause serious skin burn and eye inflammation from short wave ultraviolet radiation if outer envelope of the lamp is broken or punctured. Do not use where people will remain for more than a few minutes unless adequate shielding or other safety precautions are used. Certain lamps that will automatically extinguish when the outer envelope is broken or punctured are commercially available." This lamp complies with FDA radiation performance standard 21 CFR subchapter J. (USA:21 CFR 1040.30 Canada: SOR/DORS/80-381)
• Lamp contains mercury. Manage in Accord with Disposal Laws. See: www.lamprecycle.org or 1-800-555-0050

Specifications

General Information

• Base: E26 [ Single Contact Medium Screw]
• Operating Position: Universal [ Universal]
• Main Application: General Lighting (G)
• Life to 50% Failures (Nom): 9000 h
• ANSI Code HID: M139/O
• Features: FADEBLOCKTM [ FadeBlock™]
• Footnotes HID 1: Operate only on thermally protected ballasts. (397)

Light Technical

• Color Code: 942 [ CCT of 4200K]
• Beam Angle (Nom): 40 °
• Luminous Flux (Rated) (Nom): 4300 lm
• Luminous Intensity (Nom): 9000 cd
• Beam Description: Flood [ Flood]
• Color Designation: Cool White (CW)
• Lumen Maintenance 5000 h (Nom): 65 %
• Design Mean Lumens: 3010 lm
• Chromaticity Coordinate X (Nom): 0.371
• Chromaticity Coordinate Y (Nom): 0.366
• Correlated Color Temperature (Nom): 4200 K
• Luminous Efficacy (rated) (Nom): 61.4 lm/W
• Color Rendering Index (Min): 89
• Color Rendering Index (Nom): 94

Operating and Electrical

• Power (Rated) (Nom): 73 W
• Lamp Current (Nom): 0.83 A
• Ignition Supply Voltage (Max): 198 V
• Re-Ignition Time (Min) (Max): 10 min
• Ignition Time (Max): 30 s
• Voltage (Max): 100 V
• Voltage (Min): 75 V
• Voltage (Nom): 88 V

Mechanical and Housing

• Bulb Finish: Reflector
• Cap-Base Information: Nic/Brass
• Bulb Material: Hard Glass

UV

• Pet (Niosh) (Nom): 100 h.klx
• Damage Factor D/fc (Nom): 0.40

Luminaire Design Requirements

• Bulb Temperature (Max): 300 °C
• Cap-Base Temperature (Max): 200 °C
