Features

• Exceptional color rendering and superior color stability -- within +/- 200 K, CRI 90, 3000 K
• Low mercury, no lead; ALTO-compliant
• Operates on existing electronic and electromagnetic ballasts
• Features FadeBlock™—an integrated UV-blocking medium for reduced fading of fabrics and paintings
• Available in 35 and 70 W versions

Benefits

• Energy-efficient alternative to incandescent, halogen and standard MasterColor PAR30L lamps.
• Improved lumen maintenance over standard metal halide and standard MasterColor PAR30L lamps.
• Lamp to lamp color consistency over life.

Applications

• Ideal for display and accent lighting in retail and architectural lighting for interior and exterior applications.

Warning And Safety

• WARNING: These lamps can cause serious skin burn and eye inflammation from short wave ultraviolet radiation if outer envelope of the lamp is broken or punctured. Do not use where people will remain for more than a few minutes unless adequate shielding or other safety precautions are used. Certain lamps that will automatically extinguish when the outer envelope is broken or punctured are commercially available." This lamp complies with FDA radiation performance standard 21 CFR subchapter J. (USA:21 CFR 1040.30 Canada: SOR/DORS/80-381)
• Lamp contains mercury. Manage in Accord with Disposal Laws. See: www.lamprecycle.org or 1-800-555-0050

Specifications

General Information

• Base: E26 [ Single Contact Medium Screw]
• Operating Position: Universal [ Universal]
• Life to 5% Failures (Nom): 9000 h
• Life To 10% Failures (Nom): 10000 h
• Life to 20% Failures (Nom): 12000 h
• Life to 50% Failures (Nom): 15000 h
• ANSI Code HID: C130/E
• Switching Cycle: 1350X

Light Technical

• Color Code: 930 [ CCT of 3000K]
• Beam Angle (Nom): 30 °
• Beam Angle Technical (Nom): 28.5 °
• Luminous Intensity (Nom): 5800 cd
• Beam Description: Flood [ Flood]
• Color Designation: Warm White (WW)
• Lumen Maintenance 12000 h (Nom): 82 %
• Lumen Maintenance 2000 h (Nom): 94 %
• Lumen Maintenance 4000 h (Nom): 90 %
• Design Mean Lumens: 2040 lm
• Chromaticity Coordinate X (Nom): 0.437
• Chromaticity Coordinate Y (Nom): 0.400
• Correlated Color Temperature (Nom): 3000 K
• Luminous Efficacy (rated) (Nom): 61 lm/W
• Color Rendering Index (Min): 88
• Color Rendering Index (Nom): 91
• LLMF At End Of Nominal Lifetime (Nom): 80 %
• Luminous Flux in 90° Cone (Rated): 2100 lm

Operating and Electrical

• Power (Rated) (Nom): 39 W
• Ignition Supply Voltage (Min): 198 V
• Re-Ignition Time (Min) (Max): 15 min
• Warm Up Time to 60% Light (Nom): 120 s
• Ignition Time (Max): 30 s
• Voltage (Max): 96 V
• Voltage (Min): 80 V
• Voltage (Nom): 88 V

Controls and Dimming

• Dimmable: No
• Run-Up Time 90% (Max): 3 min

Mechanical and Housing

• Bulb Finish: Clear

Approval and Application

• Mercury (Hg) Content (Nom): 4.7 mg
• Energy Consumption kWh/1000 h: 43 kWh

Luminaire Design Requirements

• Bulb Temperature (Max): 300 °C
• Cap-Base Temperature (Max): 200 °C
