Features

• Unit Mounts Either Horizontally or Vertically, Totally Versatile, for Factories, Warehouses, Garages, Stores, Shipping Rooms, Power Stations
• Two-Toned, Smartly Styled with Stainless Steel Louvers
• Advanced Pull-Through Air Flow Design Draws Air Across Heating Element for More Even Air Distribution and Cooler Element Operation
• Branch Circuit Fusing
• Aluminum-Finned, Copper Clad Steel Sheath Heating Element has Longer Useful Life, Because of Cooler Sheath Temperature and Faster Heat Dissipation

Additional Information

• Wire Size 14 AWG
• Temperature Rating 40 to 90 Deg F

Specifications

• Voltage Rating: 480 Volt AC
• Current Rating: 12 Amp
• Power Rating: 10 Kilowatt
• Number of Phases: 3
• Capacity: 34100 BTU/Hour
• Heating Element: Aluminum Finned Copper Clad Steel Sheath
• Control Type: 24 Volt Standard Transformer
• Fan/Motor Type: 1/30 HP 1600 RPM Completely Enclosed
• Air Flow Rate: 650 CFM
• Material: Heavy Gauge Die Formed Steel
• Color: Beige
• Size: 19 Inch Width x 7-1/2 Inch Depth x 21-3/4 Inch Height
• Mounting: Horizontal/Vertical
• Application: Factory, Store, Aircraft Hanger, Garage, Power Station, Shipping Room, Warehouse
• Approval: UL (Canada and US)
• Series/Model: MUH
