Description
MARLEY M601W SPST Snap Action Line Voltage Thermostat - Electrical Distributor Control Solution
The MARLEY M601W is a line voltage thermostat designed for precise temperature control in electrical heating applications. Rated for 22 amps at 120-240V and 18 amps at 277V, this snap action thermostat is suitable for controlling resistive loads such as electric baseboards, radiant ceilings, and floor heating systems. It is compatible with a wide range of Marley heating products and recommended by electrical distributors and switchgear suppliers for reliable, manual temperature regulation.
Specifications
- Manufacturer: Marley Engineered Products
- Model Number: M601W
- Electrical Rating: 22A at 120-240V, 18A at 277V
- Type: SPST (Single Pole Single Throw) Snap Action
- Temperature Range: 45°F to 75°F
- Temperature Differential: +/- 4°F
- Compatible Load: Resistive heating loads up to 4000W @ 240V
- UL and CSA Certified
- Product Weight: 1.0 lb
- UPC: 098319841483
Features
- Bi-metal snap-action mechanism for sensitive and reliable temperature control
- Large adjustment knob for easy manual temperature setting
- Tamper-proof cover available on some models for secure installations
- Compatible with multiple Marley heating products including wall, ceiling, and fan-forced heaters
- Designed for easy installation using solderless connectors with copper wiring
- Suitable for use in commercial and residential electrical heating applications
