Made in The USA EMT Coupling 4" – Electrical Distributor Conduit Fitting

The Made in The USA EMT Coupling 4" Steel Concrete Tight fitting is designed to securely join two lengths of steel Electrical Metallic Tubing (EMT) conduit. This coupling is commonly used by electrical distributors and switchgear suppliers in lighting solutions and wire and cable installations where a durable, corrosion-resistant connection is required. Its concrete-tight design prevents the intrusion of concrete aggregate into the raceway, ensuring reliable conduit protection in concrete-embedded applications.

Specifications

• Material: Steel
• Finish: Zinc Electro-Plated for corrosion resistance
• Trade Size: 4 inches
• Length: 5.75 inches
• Width: 3.38 inches
• Weight: 2.53 lbs
• Head Type: Tri-Drive slot/Phillips/Robertson screws
• Meets NEMA Standard: FB-1
• UL Standard: UL-514B certified (UL File No. E24001)
• Federal Specification Number: W-F-408E
• Country of Manufacture: United States (Made in USA)
• Manufacturer: Bridgeport Fittings
• Manufacturer Part Number: 249-US
• Standard Package Quantity: 6 units

Features

• Concrete-tight seal prevents concrete aggregate entry into conduit raceway
• Tri-drive set screws ensure secure and durable conduit connection
• Zinc electro-plated finish enhances corrosion resistance for long service life
• Designed specifically for joining steel EMT conduit in electrical installations
• Complies with industry standards for safety and performance
• Made in the USA, supporting domestic manufacturing quality standards

Downloads and Links

• Product Photo
• Technical Drawing PDF
