Low profile Inbox for retrofit siding construction. Vertical with white paintable cover. For Dutch lap
SKU: #71503
Part: #DBVR171W
UPC: 018997143785
Low profile Inbox for retrofit siding construction. Vertical with white paintable cover. For Dutch lap
SKU: #71503
Part: #DBVR171W
UPC: 018997143785
Description
Low profile Inbox for retrofit siding construction – Electrical box for siding applications
The Low Profile IN BOX® by Arlington Industries is a recessed electrical box designed for retrofit siding construction, specifically for Dutch lap siding. This product serves as a weatherproof-in-use extra-duty cover assembly, providing a durable and paintable solution for outdoor electrical installations. It is suitable for use by electrical distributors and lighting solutions providers requiring reliable and code-compliant wire and cable enclosures for exterior applications.
Specifications
- Manufacturer Part #: DBVR171W
- Color: White
- Material: UV-Rated Plastic
- Product Weight: 1.3980 lbs
- UPC: 018997143785
- Orientation: Vertical
- Siding Lap Type: Dutch lap
Features
- Recessed box with weatherproof-in-use extra-duty cover for existing siding construction
- Non-metallic, textured, and paintable cover and base for long outdoor life
- Accepts most single gang wiring devices and standard indoor or GFCI wall plates
- One-piece assembly replaces electrical box, siding block, and bubble cover installation
- Installs flush within the wall to minimize exterior exposure
- Removable cover option for easier device installation
- No gaskets required
- Includes siding profile adapter plate, bug plugs, installation screws, NM cable connector, and caulk rolls
- Meets 2015 CEC Rule 26-702, NEMA 3R, and 2017 NEC 406.9(b) for outdoor weatherproof receptacles
