Features

• Impact resistant thermoplastic construction
• Backwired terminations for ease of installation
• Mounting screws included
• Standard Product

Specifications

• Country of Origin: Puerto Rico
• Current / Amperage Rating: 15 A
• Dimensions: 2.56 in x 2.56 in x 1.72 in
• Width: 2.700 in
• Each - Width: 2.700 in
• Height: 1.72 in
• Industry Standard(s): Certified to CSA C22.2 No. 42;Fed. Spec W-C-596;Listed to UL 498
• Length: 2.56 in
• Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - HB or better per UL94/CSA 22.2 No.0.17;Environmental - Moisture Resistance - IP20 Suitability;Environmental - Operating Temperatures - Maximum Continuous 75°C, Minimum -40°C (w/o impact);Mechanical - Terminal Accommodation - #18 AWG - #10 AWG solid or stranded copper wire only.;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
• Standards - RoHS Compliance Status: CM
• Amperage Rating: 15 A
• Application: Extra Heavy Duty Industrial
• Color: White
• Dielectric Strength: Withstands 2,000V minimum
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Insulation: Insulated Body
• NEMA Rating: L1-15P
• Number of Poles: 2-Pole
• Number of Wires: 2-Wire
• Phase: Single Phase
• Size: 2.56 in x 2.56 in x 1.72 in
• Special Features: Standard Product
• Standard: Certified to CSA C22.2 No. 42;Fed. Spec W-C-596;Listed to UL 498
• Temperature Rating: Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
• Type: Flanged Inlet
• Voltage Rating: 125 V
• Wire Size: #18 AWG to #10 AWG
• Voltage Rating Description: 125 V
• Connectivity: Screw Terminals
• Display Size: Standard Sized Product
• Nema Rating: L1-15P
• Number Of Poles: 2-Pole
• Number Of Wires: 2-Wire
• Operating Temperature: Maximum continuous 75°C and minimum -40°C without Impact
• Weight: 0.10 lb.
• Class Code: A08
• Description - Invoice: LKG FLG NLT, 15A 125V, L1-15P
• Freight Class Code: 06168002
• Harmonization Code: 8536694020
• Image Actual Or Representative: A
• MSDS Flag: No
• Replaced Catalog Number: 7524C
• Sub Class Code: A08A110
• Material - Mounting Hardware: Screw Mounting
• Current Rating: 15 A
• Material: Nylon
• Base Unit of Measure: EA
• BOX SIZE: 4.048x13.428x2.798 (in)
• Carton - Gross Weight per Pack: 1.350 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585178004
• Carton - Total Units: 10 EA
• Case - Total Units: 50 EA
• Case Weight: 5.000 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each

Certifications

• EU RoHS Indicator: Yes
