Features

• With Nightlight

Specifications

• Country of Origin: Taiwan
• Dimensions: 4.15 in x 1.82 in x 1.62 in
• Width: 3.100 in
• Each - Width: 3.100 in
• Height: 1.62 in
• Humidity: 20% to 90% non-condensing relative humidity
• Industry Standard(s): cULus Listed To UL773A
• Length: 4.15 in
• Performance: Controls - Front Press Switch - ON/OFF;Controls - Service Switch - OFF (service), ON (normal operation);Controls - Time Delay - Manual 20 seconds to 30 minutes;Electrical - Load Capacity -120VAC 600W Incandescent, 5A Ballast, 5A CFL/LED 277V, Horsepower rating 1/6;Environmental - Operating Temperature - 32°F to 122°F (0°C to 50°C) with rate of change not exceeding 20°F(11°C) per hour;Environmental - Storage - -40°F to 150°F (-40°C to 65°C), 20% to 90% non condensing relative humidity;Sensing Indicators - Passive Infrared - Red LED
• Storage Temperature Range: -40°F to 150°F (-40°C to 65°C)
• Application: Compatible with most LED and CFL
• Color: White
• Operating Temperature: 32°F to 122°F (0°C to 50°C) with rate of change not exceeding 20°F(11°C) per hour
• Size: 4.15 in x 1.82 in x 1.62 in
• Standard: cULus Listed To UL773A
• Type: Manual
• Voltage Rating: 120 VAC
• Voltage Rating Description: 120V AC
• Coverage: 1200 ft²
• Class Code: A48
• Description - Invoice: VAC SENSOR,PIR,120V 500W,NIGHT LIGHT,WH
• Freight Class Code: 06168002
• Harmonization Code: 8536507000
• Image Actual Or Representative: A
• MSDS Flag: No
• Replaced Catalog Number: RMS100ILW
• Sub Class Code: A48A450
• Mounting Height: 3.5-4.5 ft
• Photocell: Yes
• Indicator(s) Type: PIR= Red LED
• Material: ABS (Acrylonitrile butance styrene - Thermoplastic polymer)
• Series: Passive Infrared
• Base Unit of Measure: EA
• BOX SIZE: 3.700x11.800x10.200 (in)
• Carton - Gross Weight per Pack: 3.750 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585256283
• Carton - Total Units: 10 EA
• Case Weight: 3.650 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 44.400 in
• Pallet Length: 48.000 in
• Pallet Weight: 657.000 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: No
