Lighted Toggle Switch - NSI 78040TQ

This Lighted Toggle Switch, model 78040TQ by NSI Industries, is designed for motor-equipment control applications. It features a single-pole, single-throw (SPST) contact configuration with a red illuminated toggle actuator, suitable for electrical distributors and switchgear suppliers requiring reliable switching solutions. The switch offers quick-connect terminals and snap mounting for ease of installation in wire and cable assemblies and lighting solutions.

Specifications

• Contact Configuration: SPST
• Amperage Rating: 15 Amp (125 VAC) - 10 Amp (250 VAC)
• Action: Toggle Switch
• Mounting: Snap Mount
• Dimensions (L x W x H): 0.75 in x 0.422 in x 1.959 in
• Product Weight: 0.0480 lbs
• Manufacturer: NSI Industries
• Manufacturer Part #: 78040TQ
• Country of Origin: Mexico
• Terminal Type: 0.250 QuikConnect Flat
• Application: Motor-Equipment Control
• Contact Rating: 15 Amp (125 VAC) - 10 Amp (250 VAC)

Features

• Red illuminated toggle actuator for visual status indication
• Maintained contact switch with ON-OFF function
• Polycarbonate actuator for durability
• Quick-connect terminals for fast and secure wiring
• Snap mount design for easy panel installation
• Compatible with electrical distributor and lighting solutions applications
• Amperage and voltage ratings valid for DC applications

Downloads & Links

• Spec Sheet
