Features

• Controlled side can be used for wireless ON/OFF control of plugged-in electrical loads up to 15 amps such as lamps, appliances and electronics
• Tamper-resistant (TR) receptacle
• TR symbol on receptacle strap assures that it meets the NEC code requirement
• Shutter mechanism inside the TR receptacle blocks access to the contacts unless a two-prong plug is inserted, helping ensure hairpins, keys, etc. will be locked out
• Visual LED indicators for signal strength: - Red: Indicates LOW signal strength (-83dB or less) - Amber: Indicates MEDIUM signal strength (-65dB to -82dB) - Green: Indicates GOOD signal strength (-65dB and above)
• Superior versatility provides several product options in one box — 3 changeable faceplates and single pole switch capability are included
• Responds to LevNet RF Transmitters as well as EnOcean certified transmitters from other manufacturers
• ON/OFF scene control capability
• Local and remote ON/OFF control of connected loads
• Transient surge protection to IEC Level 3

Specifications

Standards and Certifications

• FCC Part 15: Class C

Environmental Specifications

• Operating Temperature: 32F to 104F 0C to 40C
• Relative Humidity: 5% to 95% non-condensing

Product Features

• Protocol: EnOcean Wireless 902 MHz
• Color: White
• Country Of Origin: China
• Neutral: Required
• Frequency: 902MHz 50-100FT
• Power Consumption: 120VAC @ 10mA AC (320mW typical)
• Product Line: LevNet RF
• Product Type: Receptacle
