Features

• All LED Exit & Emergency Lighting
• Superior Quality Exit Sign Combined with LED Energy Saving Technology In a Sealed Low-Profile, Unobtrusive Design
• Ni-Cad Battery Backup
• Completely Self-Contained
• Fully Automatic Operation
• Compact, Low Profile Design in Neutral Finish
• Push to Test Switch
• Automatic, Low Voltage Disconnect (LVD)
• 120 or 277 VAC Operation
• Injection-Molded, V-O Flame Retardant, High Impact, Polycarbonate Housing is resistant to wet, humid, washdown environment &, non hazardous dust or corrosive areas
• Clear Polycarbonate Covers
• Engineering Grade Rubber Gaskets
• Top & Side KOs for Conduit Entry
• Easy Snap-Out Directional Chevrons
• Charge Rate/Power On LED Indicator Light
• Energy Consumption of Less than 4 Watts for Red Letters and Less than 2 Watts for Green Letters
• Operating Temperature 0°F to 104°F
• Universal Mounting Plate for Wall Installation
• Listed for Wet Location
• Standard Units - 90 Minute Battery Run Time
• cULus 924 Listed
• 3 Year Warranty

Specifications

• Voltage: 120/277
• Remote Capable: No
• LED Color: Red
• Housing Color: White
• Battery: Ni-Cad
