Description
Features
- Smooth, Rounded Integral Bushings in Hubs Protect Conductor Insulation
- Accurately Tapped, Tapered Threads for Tight, Rigid Joints and Excellent Ground Continuity
- Form 35 Malleable Iron Unilets® are High Tensile Strength and Ductility, High Corrosion Resistance, High Impact and Shock Resistance
- Sizes with Flat Back Design Ideal Where Fitting is Mounted Flat against Surface
- 1/2 to 3 Inch Blank Covers are Domed for Extra Wiring Space
- Rain Tight When a Cover and Gasket are Installed
Additional Information
- Wire Size (3) 700 MCM
- Capacity 1328 Cubic Inch
- Enclosure Rating Class I Div 2
- Application Commercial/Industrial, Hazardous Location
- Applicable Standard NEC/CEC, NEMA FB-1
Specifications
- Access Opening: Back
- Configuration: LB
- Hub Location: 90 Degree
- Number of Hubs: 2
- Hub Size: 6 Inch
- Size: 25 Inch Length x 10.69 Inch Height
- Installation: Threaded
- Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Cover Screw)
- Form Type: Form 35
- Approval: UL 514A/B, CSA C22.2
- Used On: IMC/Rigid Conduit
Downloads
CatalogInstallation/Operator
Warranty
Other 1
Videos
More Information
Manufacturer Catalog Number
LB600M
Weight
56.5500
Material
Electro Zinc Plated Dichromate Epoxy Powder Coated Malleable Iron Body
Product Size
10.69 inches
