Keyway Punch – Electrical Tool for Substation and Transmission Construction

The Keyway Punch by Greenlee is designed for precise keyway creation in push-button switch applications, ideal for electrical distributors and lighting solutions providers working with wire and cable installations. It supports efficient substation and transmission construction tasks by accepting Burndy "L" dies and Alcoa "6000 Series" crimping dies. The tool's hydraulic operation and removable head facilitate quick connector removal and enhanced usability in elevated work environments.

Specifications

• Product Weight: 2.55 lbs
• Dimensions: 14.75 in (Length) x 5.3 in (Width) x 3.45 in (Height)
• Made in USA: Yes
• Country of Origin: United States
• Manufacturer: Greenlee
• Manufacturer Part #: 50265342
• UPC: 783310265344

Features

• Accepts Burndy "L" dies and Alcoa "6000 Series" crimping dies
• Top of the head swivels 90° for easy connector removal
• Equipped with 3/8" screw type hydraulic couplers
• Includes steel carrying case with storage space for dies
• Requires 10,000 psi (700 bar) hydraulic power source (single-acting for RK6040, double-acting for DK6040)
• Designed for substation and transmission construction use

Downloads & Links

• Spec Sheet
