Features

• Nylon Fitting
• Non-metallic mesh is corrosion resistant
• Neoprene bushing is oil and watertight
• Standard Product

Specifications

• Country of Origin: Puerto Rico
• Cable Diameter Range: 0.375 in-0.500 in
• Width: 3.000 in
• Each - Width: 3.000 in
• Industry Standard(s): UL Listed
• Performance: Environmental - Flammability - UL 94HB (Strand grip), UL 94V-2(Fitting);Environmental - Hazardous Locations - Suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C;Environmental - Operating Temperatures - –30°F to +225°F (–34°C to +107°C);Environmental - Wet Locations - Suitable for use in wet locations when used with a listed sealing ring between box and fitting
• Application: Straight Male- Form 2
• Conductor Range: 0.375-0.5 in (.95-1.27 mm)
• Environmental Conditions: Suitable For Use In Wet Locations When Used With A Listed Sealing Ring Between Box And Fitting.
• Number of Conductors: Single
• Special Features: Standard Product
• Standard: UL Listed
• Temperature Rating: Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
• Type: Straight Male Thread
• Cable Size: .375"-.500" (.95-1.27)
• Display Size: 1/2" NPT
• Number Of Conductors: Single
• Style: For Insulated Cables
• Thread Size: 1/2" NPT
• Class Code: A52
• Description - Invoice: STR MALE NM DCG, .375-.500"; 1/2" W/MESH
• Freight Class Code: 06168002
• Harmonization Code: 3926909985
• Image Actual Or Representative: A
• MSDS Flag: No
• Sub Class Code: A52A480
• Material - Mounting Hardware: Locknut or Tapped Opening
• Material: Nylon Fittings, Non-Metallic Mesh
• Series: Deluxe Cord Grips
• Base Unit of Measure: EA
• BOX SIZE: 4.100x10.300x4.700 (in)
• Carton - Gross Weight per Pack: 0.65 lb.
• Carton - Number of Sub Packs: 5
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585335049
• Carton - Total Units: 5 EA
• Case Weight: 3.200 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each

Certifications

• EU RoHS Indicator: Yes
