Features

• Strain relief and a Watertight seal
• Marine Wiring Applications

Specifications

• Country of Origin: United States
• Width: 3.000 in
• Each - Width: 3.000 in
• Standards - RoHS Compliance Status: CM
• Application: Straight Male
• Color: Gray
• Conductor Range: 0.63-0.75 in (15.9-19.1 mm)
• Environmental Conditions: Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
• Number of Conductors: Single
• Special Features: Marine Wiring Applications
• Temperature Rating: Minimum -30 Deg F to 225 Deg F (-43 Deg C to 107 Deg C)
• Display Size: 3/4" NPT
• Number Of Conductors: Single
• Class Code: A52
• Description - Invoice: NM CORD CONN, .62-.75"; 3/4"; GY
• Freight Class Code: 06168002
• Harmonization Code: 3926909985
• Image Actual Or Representative: A
• MSDS Flag: No
• Replaced Catalog Number: 10CM37S
• Sub Class Code: A52A490
• Material - Mounting Hardware: Locknut or Tapped Opening
• Material: Nylon
• Base Unit of Measure: EA
• BOX SIZE: 5.100x15.800x9.400 (in)
• Carton - Gross Weight per Pack: 1.8 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585808055
• Carton - Total Units: 10 EA
• Each - Pack Description: Each
• Lowest Level UOM: Each

Certifications

• EU RoHS Indicator: Yes
