INTERMATIC T106M TIME SWITCH MECHANISM - Mechanical Time Switch

The INTERMATIC T106M Time Switch Mechanism is a mechanical 24-hour dial timer designed for precise scheduling and control of electrical loads. It features a single-pole double-throw (SPDT) switch configuration suitable for various lighting solutions and electrical distributor applications. This time switch mechanism supports electrical loads typical for wire and cable installations and is compatible with standard Intermatic enclosures, making it a reliable component for switchgear suppliers and industrial timing control.

Specifications

• Manufacturer Part #: T106M
• Switch Type: 1 Normally Open, 1 Normally Closed (SPDT)
• Input Voltage: 208-277 VAC, 60 Hz
• Load Ratings: 16 A Electronic Ballast (277 VAC), 40 A Inductive, Resistive (Heater), Tungsten (Incandescent), and Pilot Duty (1000 VA, 120-240 VAC)
• Max Power Consumption: 3 W
• Motor Ratings: 2 HP, 24 FLA @ 120 VAC; 5 HP, 28 FLA @ 240 VAC
• Wire Size: #8 AWG minimum
• Operating Temperature Range: -40°F to 130°F (-40°C to 54°C)
• Product Weight: 1.3470 lbs
• UPC: 078275000285

Features

• 24-hour mechanical dial allowing up to 12 ON/OFF operations per day with minimum ON/OFF time of one hour
• Manual override lever for convenient manual control without affecting the next scheduled operation
• One ON and one OFF tripper included for easy programming
• Designed for installation in most Intermatic enclosures
• Compatible with resistive, inductive, tungsten, and electronic ballast loads
• Durable mechanism suitable for industrial and commercial electrical timing applications
