In-Wall TV Connection Kit White – recessed power and cable management

The In-Wall TV Connection Kit White provides recessed power and cable management solutions for wall-mounted flat-panel TVs in residential applications. Designed to manage excess cabling through in-wall storage and a recessed outlet, this kit allows TVs to mount flush to the wall while accommodating power for multiple devices such as cable boxes, soundbars, and streaming players. It is compatible with all TV power plugs, including right-angle cords and wall warts, making it suitable for electrical distributors and lighting solution providers focusing on wire and cable management.

Specifications

• Application: Residential
• Color: White
• Finish: Matte
• Material: High Impact Flame Retardant Plastic
• Dimensions: 9.5 in (Length) x 7.25 in (Width) x 3.25 in (Height)
• Cutout: 1 Outlet, 1 Cable Access
• Mounting: Wall Mount
• Orientation: Vertical
• Number of Gangs: 2
• Number of Outlets: 2
• Receptacle Type: 5-15R
• Amperage: 15 A
• Voltage: 125 V
• Wire Gauge: 14 AWG
• Indoor/Outdoor: Indoor
• Country of Origin: China
• RoHS Conformant: Yes
• UL Approved Components

Features

• Provides recessed power and cabling connections for flat-panel TV installations
• Manages excess cable via in-wall storage with slack for convenient access behind the TV
• Compatible with all TV power plugs, including right-angle cords and wall warts
• Unique brush strap cable catcher prevents cables from falling behind the wall
• Includes recessed wall plate with integrated low-voltage brush opening, junction box, 15A tamper-resistant outlet, and wall plate
• High impact flame retardant plastic construction for durability and safety
• Matte white finish designed to blend with typical residential wall colors

Downloads & Links

• Spec Sheet
• Cable Access Strap
• HT2102
• Product Video
• On-Q In-Wall Power & Cable Management Solutions
• HT2102WHV1 Product Environmental Profile
