In-Wall Incandescent Dimmer, Black DRD2-B
SKU: #246616
Part: #DRD2B
UPC: 754182916238
In-Wall Incandescent Dimmer, Black DRD2-B
SKU: #246616
Part: #DRD2B
UPC: 754182916238
Description
In-Wall Incandescent Dimmer, Black DRD2-B - Wireless Lighting Control
The In-Wall Incandescent Dimmer DRD2-B is designed for residential lighting control applications, enabling dimming of traditional incandescent and quartz halogen bulbs without the need for a neutral connection. As part of the RF Lighting Control System, this dimmer can be wirelessly controlled from multiple locations within the home, providing flexible lighting solutions. It is suitable for electrical distributors and switchgear suppliers looking to offer advanced wireless dimming options for residential wire and cable installations.
Specifications
- Application: Residential
- Operating Voltage: 120VAC, 60Hz
- Maximum Load Rating: 600W
- Minimum Load Required: 60W
- Load Type Compatibility: Incandescent (tungsten/quartz halogen), 60-600W
- Amperage Rating: 5 Amps
- Number of Poles: 1
- Mounting Type: Electrical Box
- Material: Plastic
- Color: Black
- Dimensions: 4.33" Length x 2.44" Width x 2.44" Height
- Product Weight: 0.36 lbs
- Manufacturer: On-Q
- Manufacturer Part Number: DRD2B
Features
- Wireless control capability as part of the RF Lighting Control System, allowing remote dimming from other devices anywhere in the home
- Does not require a neutral wire for installation, simplifying retrofit applications
- Compatible with multi-location control setups using additional wireless controllers
- Supports grouping and scene control for synchronized lighting management
- Includes Air Gap Isolation feature for safe lamp replacement
- Designed for use with incandescent and quartz halogen lamps only; not compatible with motors or diode-equipped lamps
- Derating required when installed in multi-gang boxes to prevent overheating
- Installation recommended in deep wall boxes for ease of wiring
- Complies with FCC Class B digital device limits for residential use
