Description
In-line Reducer splice kit – Wire and Cable Connector
The In-line Reducer splice kit by Burndy is designed for wire reducing splice applications, providing a reliable compression copper connection for electrical distributors and switchgear suppliers. It is suitable for joining conductors of different sizes, specifically from 2 AWG stranded to 4 AWG flexible stranded wire. This kit is engineered to support high voltage electrical systems up to 35,000 volts, making it appropriate for industrial and commercial wire and cable installations.
Specifications
- Application: Wire Reducing Splice
- Material: Copper
- Finish: Tin-Plated
- Connection Type: Reducer; Splice
- Conductor Size: 2 AWG-4 AWG
- Max. Voltage: 35000 volts
- Product Weight: 0.0620 lbs
- Manufacturer: Burndy
- Manufacturer Part #: YSR2CFX4CFXLTCKITC
- UPC: 781810429419
Features
- Compression copper reducer/splice with electro-tin plating for corrosion resistance
- Includes inspection window for cable inspection on each side
- Standard barrel design for ease of installation
- Supports high voltage applications up to 35,000 volts
