ILSCO ACON-750 750KCMIL Adapter

The ILSCO ACON-750 is a dual-rated aluminum offset pigtail adapter designed for electrical distributors and switchgear suppliers requiring reliable connections for wire and cable ranging from 750kcmil to 400kcmil. This adapter provides excellent conductivity and crimping characteristics, suitable for lighting solutions and heavy-duty electrical applications.

Specifications

• Manufacturer: ILSCO
• Manufacturer Part #: ACON-750
• Conductor Range: 750kcmil ‚Äì 400kcmil
• Dimensions (inches): Length 4.2, Width 1.735, Height 1.735
• Product Weight: 0.4090 lbs
• UL Listing: cULus listed for 35KV, 90¬∞C
• Insulating Cover: cULus listed for 600 volts, 90¬∞C

Features

• Manufactured from high strength aluminum alloy
• Offset pin configuration allows rotation for parallel applications where spacing does not fit straight pin connectors
• Chamfered barrel design for easy conductor insertion
• Prefilled with DE-OX¬Æ to prevent oxide formation
• Color-coded end caps inserted in barrel for easy identification and tooling recommendation
• Supplied with insulating cover to prevent foreign materials from entering connector prior to usage
• Provides maximum conductivity and excellent crimping characteristics
• Compatible with ILSCO and other major tooling dies for proper number and location of crimps

Downloads & Links

• Spec Sheet
