IE-110 High Frequency Noise Filter for Industrial Electrical Applications

The IE-110 is a high-frequency noise filter and surge suppressor designed for critical industrial loads drawing up to 20 Amps of continuous current. It is suitable for microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. This product is ideal for electrical distributors and switchgear suppliers seeking reliable noise attenuation and transient protection in industrial environments.

Specifications

• Current Rating: 10 amperes
• Frequency Rating: 47-63 Hz
• Circuit Type: 1-Phase 2-Wire
• Protection Mode: Line-Neutral (L-N), Line-Ground (L-G), Neutral-Ground (N-G)
• Noise Attenuation: 90 dB minimum at 100 kHz to 50 MHz (Normal Mode), 60 dB minimum at 5 MHz to 50 MHz (Common Mode)
• Maximum Continuous Operating Voltage (MCOV): 120 V
• Operating Temperature: -40¬∞C to +45¬∞C
• Operating Humidity: 0% to 95%
• Mounting Type: DIN rail or flange
• Connection: IEC 998 approved terminals
• Weight: 1.3 lbs
• Approvals: UL 1283/1449, CUL, CE
• Manufacturer Part Number: IE-110

Features

• Multi-staged design combining hybrid clamping network with active tracking technology
• Surge current capacity of 45,000 Amps
• Transient protection in all modes: line to neutral, line to ground, and neutral to ground
• LED status indication and form C contact for remote monitoring
• DIN mountable enclosure for easy installation
• Compliance with ANSI/UL 1449 Third Edition Type 4, UL 1283, CUL recognized, and CE certified
• 10-year warranty
