IE-105 High Frequency Noise Filter for Industrial Electrical Applications

The IE-105 is a high-frequency noise filter designed for critical industrial loads drawing up to 5 amperes of continuous current. It is suitable for microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. This device is ideal for electrical distributors and switchgear suppliers seeking reliable noise attenuation and surge suppression in industrial environments.

Specifications

• Current Rating: 5 amperes
• Frequency Rating: 47 to 63 Hz
• Circuit Type: 1-Phase 2-Wire
• Protection Mode: Line-Neutral, Line-Ground, Neutral-Ground
• Noise Attenuation: 90 dB minimum (Normal Mode, 100 kHz to 50 MHz), 60 dB minimum (Common Mode, 5 MHz to 50 MHz)
• MCOV: 120 V
• Operating Temperature: -40¬∞C to +45¬∞C
• Environmental Conditions: Humidity 0% to 95%
• Mounting Type: DIN Rail or Flange
• Connection: IEC 998 approved terminals
• Weight: 0.95 lbs
• Approvals: UL 1283/1449, CUL, CE

Features

• Multi-staged design with hybrid clamping network and active tracking technology
• Surge current capacity of 45,000 Amps
• Transient protection in all modes: line to neutral, line to ground, and neutral to ground
• LED status indication with form C contact for remote monitoring
• Compact DIN mountable enclosure
• ANSI/UL 1449 Third Edition Type 4 certified
• 10-year warranty
