IDEAL 89-610 BARRIER STRIP 12-CIRCUIT – Electrical Connector for Wire Termination

The IDEAL 89-610 Barrier Strip is a 12-circuit electrical connector designed for secure and reliable wire termination in electrical distribution and lighting solutions. Manufactured by Ideal Industries, this barrier strip is suitable for connecting stripped, un-terminated solid or stranded wire directly to each contact, making it ideal for use by electrical distributors and switchgear suppliers. Its plastic housing and modular design allow for flexible installation in wire and cable applications requiring safe and durable connections.

Specifications

• Material: Plastic Housing
• Amperage Rating: 30 AMP, 20 AMP
• Number of Circuits: 12
• Wire Range: 22 - 10 AWG (per catalog data for part 89-610)
• Operating Temperature: Rated to 105°C (221°F)
• Dimensions (inches): Length 4.626, Width 0.795, Height 0.670 (approximate from catalog)
• Torque: 4.4 in.-lb.

Features

• Recessed screws and tubular contacts provide added safety and help prevent short circuits
• Tubular contacts connect stripped, un-terminated solid or stranded wire directly to each contact
• Integrated wire protectors prevent twisting and breakage of stranded wire during connection
• Modular 12-circuit design can be cut into smaller sections or stacked end-to-end for flexible installation
• Rugged nylon construction, UL 94V2 rated for durability
