IC+202, High Frequency Noise Filter – Electrical Noise Suppression

The IC+202 High Frequency Noise Filter by Emerson is designed to provide high-frequency noise attenuation and transient protection for industrial and office equipment, including computers operating in harsh environments. This product is suitable for electrical distributors and lighting solutions providers looking to offer effective wire and cable noise suppression and switchgear supplier applications. It supports critical loads up to 30 amperes and ensures protection across multiple modes including line-to-neutral, line-to-ground, and neutral-to-ground.

Specifications

• Application: Industrial or office equipment, computers placed in harsh environments
• Current Rating: 2.5 amperes
• Frequency Rating: 47-63 Hz
• Noise Attenuation: 90 dB minimum at 100 kHz to 50 MHz (Normal Mode), 60 dB minimum at 5 MHz to 50 MHz (Common Mode)
• MCOV: 240 V
• Operating Temperature: -40 to 45 ¬∞C
• Operating Humidity: 0 to 95%
• Size: 4 inch L x 2.88 inch W x 1.81 inch H
• Material: High Impact Plastic Case, Vacuum Impregnated Magnetics, Epoxy Encapsulated
• Mounting Type: Flange (Dimensions: 8.25 x 3.50 x 9.00 x 0.19 in)
• Connection: Barrier strip at input and output with wire leads at input and output
• Approvals: UL 1283, CSA recognized
• Product Weight: 1.2 lbs
• Manufacturer: Emerson
• Manufacturer Part #: IC+202
• Class: Category A Ringwave (6 kV, 200 A, 100 kHz)

Features

• High-frequency noise filter with transient protection for critical loads up to 30 amperes
• Typically reduces normal mode transients to ¬±2 volts
• Surge current capacity of 45,000 Amps
• Transient protection in all modes: line-to-neutral, line-to-ground, and neutral-to-ground
• LED status indication for power monitoring
• Solid-state resettable fuses (PTCs) and silicon breakover technology
• Low capacitance design suitable for sensitive equipment
• Flange mounting for secure installation
• 10-year warranty
