HUBBELL HBL5360WSA Duplex Surge Protection Receptacle 20A 125V

The HUBBELL HBL5360WSA is a decorator duplex surge protection receptacle designed for indoor dry environments. It provides transient voltage surge suppression for sensitive electronic equipment, making it suitable for electrical distributors, lighting solutions, wire and cable systems, and switchgear suppliers seeking reliable surge protection at the point of use. This device is rated for 20 amperes at 125 volts AC and features a straight blade outlet configuration.

Specifications

• Application: Decorator Duplex
• Amperage Rating: 20 A
• Voltage Rating: 125 V AC
• Frequency Rating, Maximum: 60 Hz
• Material: Composite
• Mounting: Screws Mounting
• Connection: Terminals
• Outlet: Straight Blade
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Product Weight: 3.0000 lbs
• Manufacturer: Hubbell Building & Automation
• Manufacturer Part Number: HBL5360WSA
• UPC: 783585219899

Features

• Type 3 Surge Protective Device (SPD) with 240 joules minimum peak energy dissipation
• Suppresses transient voltage spikes to protect sensitive electronics
• Green LED indicator shows presence of surge protection and power
• Internal protection disconnects surge component at end of life while maintaining power to load
• UL Listed to standards 498 and 1449, Edition 3
• CSA Certified for 15A devices (applicable certification for 20A not specified)
• Designed for installation by qualified electricians following national and local electrical codes
• Use copper conductors only, with terminal capacity from #14 to #10 AWG
