Description
HUBBELL HBL5262WSA Duplex Surge Protective Receptacle with Alarm
This Hubbell HBL5262WSA is a decorator duplex surge protective receptacle designed for indoor dry environments. It provides transient voltage surge suppression with both visual and audible alarms to indicate surge protection status. Ideal for sensitive electronic equipment protection, this device is suitable for electrical distributors and lighting solutions requiring reliable surge suppression integrated into standard wiring devices.
Specifications
- Application: Decorator Duplex with Light and Alarm
- Amperage Rating: 15 A
- Voltage Rating: 125 VAC, 60 Hz
- Class: Normal and Common Mode
- Outlet: Straight Blade (NEMA 5-15R)
- Material: Composite
- Mounting: Mounting Screws
- Connection: Terminal Screws
- Environmental Conditions: Indoor Dry Unless Protected By Additional Means
- Manufacturer: Hubbell Building & Automation
- Manufacturer Part #: HBL5262WSA
- Product Weight: 0.25 lbs
- UPC: 783585060194
- Surge Protection Energy Rating: 240 Joules minimum
- Peak Surge Current: 15,000 amperes
- UL Voltage Protection Level: 600V Peak (L-N and L-G, 8x20 µs, 3kA)
- Receptacle Leakage Current: 0.5 mA max at 25°C, 120VAC
- Operating Temperature Range: 0° to 40°C (32°F to 104°F)
- Storage Temperature Range: -35°C to 60°C (-31°F to 140°F)
Features
- Integrated LED indicator shows when surge protection is active (green light on)
- Audible alarm sounds continuously if surge protection is lost; alarm can be silenced via front panel screw
- Internal protection disconnects surge suppressor at end of life while maintaining power to connected load (unprotected)
- Designed for use on 125 VAC branch circuits with 20 Amp maximum overcurrent protection
- Terminal capacity supports #14 to #10 AWG copper conductors
- Meets UL Listed Standards 498 and 1449 (3rd edition) and CSA Certified to Specification C22.2 No. 42M (15A only)
- Suitable for installation by qualified electricians in accordance with national and local electrical codes
