Hubbell Building & Automation
HUBBELL 1223R SWITCH HUBPRO 3-WAY 20A 120/277V RD
SKU: #136219
Part: #1223R
UPC: 783585154541
Hubbell Building & Automation
HUBBELL 1223R SWITCH HUBPRO 3-WAY 20A 120/277V RD
SKU: #136219
Part: #1223R
UPC: 783585154541
Description
HUBBELL 1223R SWITCH HUBPRO 3-WAY 20A 120/277V RD - Industrial Electrical Switch
The HUBBELL 1223R Switch HubPro is a 3-way toggle switch designed for heavy-duty industrial applications. It operates at 20 amps and supports 120/277V AC, suitable for indoor dry environments unless additional protection is provided. This switch is back and side wired, providing flexible wiring options for electrical distributors and lighting solutions requiring reliable switching control.
Specifications
- Name: HUBBELL 1223R SWITCH HUBPRO 3-WAY 20A 120/277V RD
- Amperage Rating: 20 A
- Voltage Rating: 120/277V AC
- Contact Rating: Per UL 20
- Number of Poles: Single Pole
- Contact Configuration: Two Position (SPDT)
- Operating Cycles: 50,000 Cycles
- Mounting: Screw Mount
- Connection: Back and Side Wired
- Environmental Conditions: Indoor Dry unless protected by additional means
- Product Weight: 0.1500 lbs
- Manufacturer: Hubbell Building & Automation
- Manufacturer Part #: 1223R
Features
- Heavy-duty industrial series switch designed for 3-way applications
- Back and side wired terminals for versatile installation
- Durable toggle mechanism rated for 50,000 operating cycles
- SPDT action providing reliable two-position switching
- Suitable for use in lighting and electrical distribution systems
