Features

• Butt hinges on door
• Various sizes of easily removable concentric knockouts on all four sides
• Mounting holes on back of box
• Provision for grounding

Specifications

• Length: 12.00 inch
• Width: 12.50 inch
• Height: 6.20 inch
• Weight: 10.50 pound
• Height (H) (inch): 12
• Height (H) (millimetre): 305
• Width (W) (inch): 12
• Width (W) (millimetre): 305
• Depth (D) (inch): 6
• Depth (D) (millimetre): 152
• Protection Rating: NEMA Type 1
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness (T) (gauge): 16
• Thickness (T) (millimetre): 1.52
• Knockout Pattern Along A Sides: C-D-E-F-G
• Knockout Pattern Along B Sides: C-D-E-F-G
• NEMA Rating: 1 Indoor, electrical protection
• Modification Services: Yes
• Type Number: Type 1
• IP Rating: IP30
• Weight (pound): 10.5
• Size: 12.00x12.00x6.00 in
• Knockouts: Yes
