HID-45-EX39-850-BYP-PT LED HID Replacement Lamp

The HID-45-EX39-850-BYP-PT by RAB is a high-performance LED replacement lamp designed for traditional Metal Halide or High Pressure Sodium HID fixtures. Suitable for electrical distributors and lighting solutions providers, this lamp features an integral driver for direct wiring to line voltage, eliminating the need for external ballasts. It is ideal for outdoor applications in enclosed or open fixtures, offering reliable performance in dry or damp locations. The lamp supports ballast bypass installation (Type B) and provides efficient lighting with high color accuracy and long lifespan, making it a practical choice for switchgear suppliers and wire and cable integrators aiming for energy-efficient upgrades.

Specifications

• Manufacturer: RAB
• Model Number: HID-45-EX39-850-BYP-PT
• Input Voltage: 100-277 volts
• Input Wattage: 45 watts
• Lumens: 6,800 lumens
• Efficacy: 151 lumens per watt
• Color Temperature: 5000 kelvins (Daylight)
• Color Rendering Index (CRI): 80
• Beam Angle: 360 degrees
• Base Type: EX39
• Bulb Shape: Post Top
• Operating Frequency: 50/60 Hz
• Operating Temperature Range: -30¬∞C to 60¬∞C
• Equivalent to: 175W HID
• Product Weight: 2.0 lbs
• Installation Type: Type B, Ballast Bypass
• Installation Orientation: Universal
• UL Listed and UL Classified
• Design Lights Consortium (DLC) Qualified
• Non-Dimmable
• Power Factor: 0.9
• Total Harmonic Distortion (THD): <20%
• Surge Protection: 4kV built-in
• Lifespan: 50,000 hours

Features

• Direct line voltage wiring with integral driver, no external ballast required
• Active cooling system reduces output to 70% during sensor overheat, restoring to 100% when cooled
• Rated for use in enclosed and open fixtures in dry or damp environments
• Environmentally friendly with no mercury content
• 5-year no compromise warranty covering light output, color stability, driver performance, and fixture finish
• Meets DLC 5 requirements and eligible for rebates from DLC member utilities
