HID-36-E26-850-BYP-PT LED HID Replacement Lamp

The HID-36-E26-850-BYP-PT is an LED replacement lamp designed for traditional Metal Halide or High Pressure Sodium HID fixtures. It is suitable for use in enclosed and open fixtures, making it ideal for outdoor lighting applications. This lamp offers efficient lighting solutions for electrical distributors and switchgear suppliers requiring reliable wire and cable compatible lighting components with high performance and long lifespan.

Specifications

• Product Type: HID Replacement
• Input Wattage: 36W
• Lumens: 5,400 lumens
• Efficacy: 150 lumens per watt
• Color Accuracy (CRI): 80
• Color Temperature: 5000 kelvins (Daylight)
• Base Type: E26
• Bulb Shape: Post Top
• Beam Angle: 360 degrees
• Input Voltage: 100-277 volts
• Operating Frequency: 50/60 hertz
• Operating Temperature: -30 to 60 degrees Celsius
• L70 Lifespan: 50,000 hours
• Equivalency: 150W HID
• Power Factor: 0.9
• Dimmable: No
• UL Listed: Yes
• UL Classified: Yes
• CEC Status: Lawful for sale in California

Features

• Replacement for traditional Metal Halide or High Pressure Sodium HID lamps
• Active Cooling with internal sensor reduces output to 70% when overheating, restoring to 100% after cooling
• Integral driver allows direct wiring to line voltage without external driver or ballast
• Rated for use in dry or damp locations, both enclosed and open fixtures
• 4kV surge protection built-in
• Environmentally friendly, mercury-free
• Non-dimmable design
• 5 Year No Compromise Warranty covering light output, color stability, driver performance, and fixture finish
