Hex Head Split Bolts #6 – Copper Electrical Connector

The Hex Head Split Bolts #6 are designed for secure electrical connections in wire and cable applications. Manufactured from high-strength electrolytic copper alloy, these connectors ensure maximum conductivity and durability. Suitable for copper conductors ranging from #8 to 750 MCM, they are ideal for use by electrical distributors and switchgear suppliers in grounding and bonding applications. Rated for 600V and 90°C, these split bolts meet UL467 standards for direct burial and are reusable, supporting reliable lighting solutions and electrical installations.

Specifications

• Conductor Size: #8 to 750 MCM
• Material: High Strength Electrolytic Copper (Body), Copper Alloy (Nut and Spacer)
• Temperature Rating: 90°C
• Voltage Rating: 600V
• UL Listing: UL467 for Direct Burial and Grounding/Bonding
• CSA Certified
• Product Weight: 0.2500 lbs

Features

• Manufactured from high conductivity electrolytic copper alloy for maximum strength and conductivity
• Rated exclusively for copper conductors
• Connectors are reusable
• UL486 UL 486A-486B & CSA C22.2 No. 65-13 compliant
• UL467 DB Listed for direct burial and grounding applications

Downloads & Links

• Spec Sheet
