Heavy Duty Products, Insulgrip Pin and Sleeve Devices, Industrial Grade, Female, Plug, 200A 600V AC, 4-Pole 5- Wire Grounding, Terminal Screws, Gray and Black, Watertight
SKU: #144102
Part: #HBL5200PS1W
UPC: 783585011547
Heavy Duty Products, Insulgrip Pin and Sleeve Devices, Industrial Grade, Female, Plug, 200A 600V AC, 4-Pole 5- Wire Grounding, Terminal Screws, Gray and Black, Watertight
SKU: #144102
Part: #HBL5200PS1W
UPC: 783585011547
Description
Heavy Duty Insulgrip Pin and Sleeve Devices – Industrial Grade Female Plug 200A 600V AC
This heavy duty Insulgrip pin and sleeve plug is designed for industrial electrical applications requiring reliable and durable connections. It is suitable for use by electrical distributors, lighting solutions providers, and switchgear suppliers needing a watertight, high amperage connector for wire and cable systems. The device features a metallic housing with a nylon shroud for impact resistance and protection against bending or breaking. It supports 4-pole, 5-wire grounding configurations at 200 amperes and 600 volts AC, making it ideal for heavy-duty portable power connections.
Specifications
- Manufacturer: Hubbell Wiring Device-Kellems
- Catalog Number: HBL5200PS1W
- Current Rating: 200 amperes
- Voltage Rating: 600V AC RMS
- Number of Poles: 4-Pole
- Number of Wires: 5-Wire
- Material: Composite housing with aluminum plug shroud
- Mounting: Cord Mounted
- Cord Type: All Portable
- Connection: Pressure Terminal Screws
- Environmental Rating: Watertight, UL Type 4X dust-tight seal
- Dimensions (Width): 8.1 in
- Weight: 11.35 lbs
- Country of Origin: United States
- NEMA Rating: Non-NEMA
Features
- Impact resistant shroud protects sleeves from bending and breaking
- Locking ring provides UL Type 4X watertight and dust-tight seal
- All-brass sleeve contacts ensure reliable electrical contact
- Catalog number and rating remain visible while in use
- Terminal screws provide secure pressure connections
- Operates in harsh environments with watertight sealing
- Meets UL 1682, UL 50, UL 1010, and CSA C22.2 No. 159 standards
- Flammability rating UL 94V-0 and CSA C22.2 No. 0.17
- Operating temperature range from -40°C (without impact) to 75°C continuous
